WL200/WL220/WL220T – Pure Line WL Series Lab Water Purifiers – Yamato




Yamato’s Pure Line economical and space saving benchtop WL series water purifier connects directly to tap water. Deionized purified ASTM type 2 water is continuously produced. The WL220T is additionally equipped with constant temperature control and has a 3L pure water tank. All units come standard with a membrane filter at the sampling port and a solenoid valve that prevents water leakage from final membrane filter. It displays alerts for consumable replacements and keeps track of replacement history.

Performance and functions

  • Collecting deionized water is as simple as connecting to a faucet
  • Benchtop, space-saving design
  • Digital display for easy operation
  • Deionized water compliant with ASTM D1193 Type 2 / JIS K 0557 A3 level, suitable for trace analysis
  • Displays replacement of consumables
  • Standard equipped with membrane filter (WL200/220)
  • A solenoid valve at the water sampling port prevents water leakage from final membrane filter
  • WL220T is equipped with constant temperature control and pure water tank. Constant temperature and deionized water delivery to pure water tank controlled by electromagnetic valve
Specifications WL200 WL220 WL220T
Water Purifying Method Ion-exchange (controlled by key) Ion-exchange (manual)
Raw Water Supply One touch coupler water connection resin hose
Deionized Water Production ~1L/min. (continuously produced) ~1L/min. (by natural fall)
Ion-Exchange Resin Cartridge 2L ion-exchange resin with activated carbon (CPC-P) x 1pc. 2L ion-exchange resin with activated carbon (CPC-P) x 1pc. 2L ion-exchange resin (CPC-E) x 1pc.
Final Filtration 0.1µm (membrane filter) N/A
Pure Water Tank N/A N/A 3L polyethylene tank
Water Leakage Detection Solenoid valve forced shutdown of water supply by detecting water leakage
Raw Water Pressure Range 0.5~5x100kPa (0.5~5 kgf/cm²)
Sampling Port 250mm above floor RC1/4 (membrane filter connection) ø9 nipple (hose connection)
Safety Device Circuit breaker, water leakage indicator, pressure reducing valve, water quality abnormal alarm
Power Source (50/60Hz) AC100~240V < 0.2A
External Dimensions* W350xD350xH450mm
Weight 14kg 16kg 17kg
Water Quality Display 7 segments LED display (conductivity / resistivity)
Other Display Display of consumables replacement (CPC-P and CPC-E: should be replaced simultaneously to prevent degradation of water quality, membrane filter), alarm display (water leakage alarm)
SKU: WL200/WL220/WL220T Categories: , Tags: , , Brand:
Weight 30.86 lbs
Dimensions 30.86 × 30.86 × 17.72 in

WL-200 (DEIONIZED WATER PURIFIER ~1.0L/min 100-240V), WL-220 (DEIONIZED WATER PURIFIER ~1.0L/min 100-240V), WL-220T (DEIONIZED WATER PURIFIER ~1.0L/min 3L tank 100-240V)
