SCO6AD- CO2 INC, AJ, 5.9 CUFT, HIGH HEAT DECON, HEPA – Shellab


Compare

Extensive use of copper in the CO2 sample port, humidity reservoir, and heated CO2 feed line adds reassurance that foreign microbes will not affect test results

$6,837.00

Clear

Contamination ControlExtensive use of copper in the CO2 sample port, humidity reservoir, and heated CO2 feed line adds reassurance that foreign microbes will not affect test results. Cleanup is a breeze with the all stainless steel chamber, coved corners, and autoclavable door gasket. Optional copper shelves are available for additional contamination control.

SCO6AD Unit Specification Chart SCO6AD
Interior Volume, Nominal 5.9 cu.ft. (167 liters)
Interior Dimensions W x D x H 20.2″ x 20.0″ x 25.5″
513 x 508 x 647 mm
Exterior Dimensions(w x d x h) 28.5″ x 30.8″ x 39.5″
724 x 782 x 1003 mm
Interior Construction 300 series stainless steel
Exterior Construction 20 gauge steel, powder coated
Shelves (See Accessories)* 3 standard, 8 total
Maximum Weight Per Shelf* 35 lb / 15.8 kg
Permitted Total Load 105 lb / 47.6kg
Order Model Number, Voltage Specific SCO6AD
SCO6AD SCO6AD-2
Electrical, 50/60Hz, AC, 1Ø
Voltage 110V-120V 220V-240V
Full Load Amps 12 6.0
Nominal Power (watts @37°C) 130 110
Recommended Breaker, Amps 15 15
Power Cord Supplied NEMA5-15P EU1-16P
CO2 Range 1-20% 1-20%
Recovery CO2 at 5%* < 5 min. < 5 min.
Sensor Type Infrared Infrared
Temperature Uniformity
At 37°C ± 0.25°C ± 0.25°C
Humidity Range Passive (Ambient 95%)
Temperature Range Recovery 37°C*
Recovery to 37°C after 30 sec. Door Opening 6.0 min. 6.0 min.
SKU: SCO6AD / SCO6AD-2 Categories: , , Tags: , , Brand:
Weight 268 lbs
Dimensions 30.8 × 28.5 × 39.5 in
Product

SCO6AD (100-120V ), SCO6AD-2 (220-230V)
