SCO31 /SCO40/SCO58- SCO Series Large Capacity Units – Shellab


Compare

The advanced PID (proportional, integral, derivative) controller commands proportional power to the heating elements and CO2 injection frequency to provide the most accurate and responsive control.

$13,164.00$19,289.00

Clear

Contamination ControlExtensive use of copper in the humidity heated CO2 feed line and precise airflow management designed to prevent condensation adds reassurance that foreign microbes will not affect test results. Cleanup is a breeze with the all stainless steel chamber.

SCO CO2 Incubators Water Jacketed Series Specification Chart
  SCO31 SCO40 SCO58
Interior Volume, Nominal 31.4 cu.ft. (890.7 liters) 39.5 cu.ft. (1118 liters) 58 cu.ft. (1641 liters)
Interior Dimensions W x D x H 32.9″ x 26.1″ x 63.3″
836 x 663 x 1608 mm
34.7″ x 25.8″ x 76.2″
881 x 655 x 1935 mm
43.0″ x 34.5″ x 67.5″
1092 x 876 x 1715 mm
Exterior Dimensions(w x d x h) 39.6″ x 33.7″ x 76.2″
1005 x 851 x 1936 mm
42.2″ x 33.5″ x 88.0″
1071 x 851 x 2235 mm
51.0″ x 44.8″ x 81.0″
1295 x 1137 x 2057 mm
Interior Construction 300 series stainless
steel
300 series stainless
steel
300 series stainless
steel
Exterior Construction 20 gauge steel,
powder coated
20 gauge steel,
powder coated
20 gauge steel,
powder coated
Shelves (See Accessories)* 6 standard, 30 total 6 standard, 30 total 6 standard, 30 total
Maximum Weight Per Shelf* 50 lb / 22.7 kg 50 lb / 22.7 kg 50 lb / 22.7 kg
Permitted Total Load 300 lb / 136.1 kg 300 lb / 136.1 kg 300 lb / 136.1 kg
Order Model Number, Voltage Specific SCO31 SCO40 SCO58
SCO31 SCO31-2 SCO40 SCO40-2 SCO58 SCO58-2
Electrical, 50/60Hz, AC, 1Ø
Voltage 110V-120V 220V-240V 110V-120V 220V-240V 110V-120V 220V-240V
Full Load Amps 14.5 8.0 15.0 9.0 15.0 8.0
Nominal Power (watts @37°C) 321 300 365 340 385 350
Recommended Breaker, Amps 15 16 20 16 20 16
Plug Supplied NEMA5-20P EU1-16P NEMA5-20P EU1-16P NEMA5-20P EU1-16P
CO2 Range 1-20% 1-20% 1-20% 1-20% 1-20% 1-20%
Recovery CO2 at 5%* < 5 min. < 5 min. < 5 min. < 5 min. < 5 min. < 5 min.
Sensor Type Infrared Infrared Infrared Infrared Infrared Infrared
Temperature Uniformity
At 37°C ± 0.5°C ± 0.5°C ± 0.5°C ± 0.5°C ± 0.5°C ± 0.5°C
Temperature Range Ambient +8°C to 60°C
Temperature Recovery 37°C
Recovery to 37°C after 30 sec. Door Opening 8.0 min. 8.0 min. 7.0 min 7.0 min 7.0 min 7.0 min
SKU: SCO31 /SCO40/SCO58 Categories: , , Tags: , , , Brand:
Weight N/A
Dimensions N/A
Product

SCO31 (100-120V ), SCO31-2 (220-230V), SCO40 (110-120V ), SCO40-2 (220-230V), SCO58 (110-120V ), SCO58-2 (220-230V)
