BIT-16,BIT-35,BIT-55,BIT-120,BIT-200 – Natural Convection Heating Incubator Being
The applications of the laboratory incubators are diverse due to the different industries and protocols for which they are used, which is why we have designed the BEING LAB family of incubators to accommodate a wide range of applications.
$1,000.00 – $2,500.00
The applications of the laboratory incubator are diverse due to the different industries and protocols for which they are used, which is why we have designed the BEING LAB family of incubators to accommodate a wide range of applications. The BEING controller guarantees precision and temperature control. We design the best security features in all our products, ensuring peace of mind for our customers.
characteristics:
- Colorful LCD screen.
- Double door with interior glass door that allows the display of full width samples.
- Interior camera made of 304 stainless steel with a polished glossy finish that facilitates cleaning.
- Roll shelves help prevent accidents when moving shelves.
- The upper central portal allows real-time testing of the internal temperature of the chamber using external temperature measurement equipment.
- The Pt100 temperature sensor provides sensitivity and precision at high temperatures.
- The BEING controller provides programming for 7 periods and 9 steps for each period, making a total of 63 programmable steps.
| (inch) | A | second | do | re | my | F | GRAM | H |
| BIT-16 | 20.0 | 11.2 | 1.0 | 3.0 | 11.8 | 14.7 | 15.6 | 8.6 |
| BIT-35 | 23.0 | 12.6 | 1.0 | 3.0 | 14.0 | 22.2 | 17.7 | 11.8 |
| BIT-55 | 26.2 | 15.8 | 1.2 | 3.9 | 16.3 | 24.8 | 18.4 | 13.0 |
| BIT-120 | 30.9 | 20.5 | 1.2 | 6.7 | 20.9 | 29.3 | 23.2 | 17.7 |
| BIT-200 | 36.0 | 25.6 | 1.2 | 9.8 | 25.6 | 35.49 | 25.6 | 23.6 |
| Model | BIT-16 | BIT-35 | BIT-55 | BIT-120 | BIT-200 |
| Camera volume | 0.6 Cu ft 18 Litros | 1.2 With ft 34 Litros | 1.9 With ft 54 Litros | 4.4 Cu ft 124 Litros | 7.8 cubic feet 222 liters |
| Temperature range | Environment + 9 ℉ ~ 176 ℉, Environment + 5 ℃ ~ 80 ℃ | ||||
| Temperature stability | 0.36 ℉, 0.2 ℃ | ||||
| Screen resolution | 0.1 | ||||
| Cantidad estándar / máxima de estantes | 2/5 | 2/5 | 2/9 | 2/12 | 2/16 |
| Max. carga por estante | 20 kg | ||||
| Dimensión interna (W * H * D) | 11,2 × 11,8 × 8,6 (pulgada) 285 × 299 × 219 (mm) |
12.6 × 14.0 × 11.8 (pulgada) 320 × 355 × 300 (milímetro) |
15,8 × 16,3 × 13,0 (pulgada) 400 × 415 × 330 (mm) |
20,5 × 20,9 × 17,7 (pulgada) 520 × 530 × 450 (mm) |
36.0 × 35.5 × 25.6 (pulgada) 915 × 900 × 658 (mm) |
| Dimensión externa (W * H * D) | 20.0 × 14.7 × 15.6 (pulgada) 508 × 373 × 395 (milímetro) |
23,0 × 22,2 × 17,7 (pulgada) 585 × 565 × 450 (mm) |
26,2 × 24,8 × 18,4 (pulgada) 665 × 630 × 468 (mm) |
31 × 29,3 × 23,2 (pulgada) 785 × 745 × 595 (mm) |
36.0 × 35.5 × 25.6 (pulgada) 915 × 900 × 658 (mm) |
| Peso neto | 23Kg | 44Kg | 53Kg | 79Kg | 108Kg |
| Minutero | 1 ~ 5999 minutes | ||||
| Electrical requirement | AC120V, 60Hz | ||||
| The energy consumption | 130W | 250W | 300W | 550W | 700W |
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Product | BIT-16,120VAC,50/60Hz, BIT-16,230VAC,50/60Hz, BIT-35, 120VAC,50/60Hz, BIT-35, 230VAC,50/60Hz, BIT-55, 120VAC,50/60Hz, BIT-55, 230VAC,50/60Hz, BIT-120, 120VAC,50/60Hz, BIT-120, 230VAC,50/60Hz, BIT-200, 120VAC,50/60Hz, BIT-200, 230VAC,50/60Hz |
